#1 2010-06-29 11:07:39
[Tomato ND USB] WL-500gP/WL-500W 128MB RAM
之前 WL-500gP 使用泰迪熊v1.27, 皆能開啟128MB RAM. Erase all data in NVRAM memory(thorough)會回復到64MB, 但設定sdram_init=0x0011後, 就可開啟128MB. Restore default router settings(normal)則不會修改sdram_init值, 可維持128MB RAM.
近日才發現怎麼只剩64MB? 於泰迪熊v1.27.8747或v1.27.9047beta16, 皆只能辨識到64MB.
設定sdram_init=0x0011後, 自動切回64MB. console訊息:
CFE version 1.0.37 for BCM947XX (32bit,SP,LE)
Build Date: ¥| 10¤ë 12 22:21:19 CST 2006 (root@localhost.localdomain)
Copyright (C) 2000,2001,2002,2003 Broadcom Corporation.
Initializing Arena
Initializing Devices.
et0: Broadcom BCM47xx 10/100 Mbps Ethernet Controller 3.90.7.0
rndis0: Broadcom USB RNDIS Network Adapter (P-t-P)
CPU type 0x29006: 264MHz
Total memory: 134217728 KBytes
Total memory used by CFE: 0x80800000 - 0x8089AF40 (634688)
Initialized Data: 0x808313D0 - 0x80833790 (9152)
BSS Area: 0x80833790 - 0x80834F40 (6064)
Local Heap: 0x80834F40 - 0x80898F40 (409600)
Stack Area: 0x80898F40 - 0x8089AF40 (8192)
Text (code) segment: 0x80800000 - 0x808313D0 (201680)
Boot area (physical): 0x0089B000 - 0x008DB000
Relocation Factor: I:00000000 - D:00000000
...
Mounted devfs on /dev
Freeing unused kernel memory: 80k freed
Hit ENTER for console...
Restarting system.
Please stand by while rebooting the system...
CFE version 1.0.37 for BCM947XX (32bit,SP,LE)
Build Date: ¥| 10¤ë 12 22:21:19 CST 2006 (root@localhost.localdomain)
Copyright (C) 2000,2001,2002,2003 Broadcom Corporation.
Initializing Arena
Initializing Devices.
et0: Broadcom BCM47xx 10/100 Mbps Ethernet Controller 3.90.7.0
rndis0: Broadcom USB RNDIS Network Adapter (P-t-P)
CPU type 0x29006: 264MHz
Total memory: 67108864 KBytes
Total memory used by CFE: 0x80800000 - 0x8089AF40 (634688)
Initialized Data: 0x808313D0 - 0x80833790 (9152)
BSS Area: 0x80833790 - 0x80834F40 (6064)
Local Heap: 0x80834F40 - 0x80898F40 (409600)
Stack Area: 0x80898F40 - 0x8089AF40 (8192)
Text (code) segment: 0x80800000 - 0x808313D0 (201680)
Boot area (physical): 0x0089B000 - 0x008DB000
Relocation Factor: I:00000000 - D:00000000
...
Mounted devfs on /dev
Freeing unused kernel memory: 80k freed
Hit ENTER for console...
eth0: Broadcom BCM47xx 10/100 Mbps Ethernet Controller 4.150.10.29
PCI: Enabling device 01:02.0 (0004 -> 0006)
eth1: Broadcom BCM4318 802.11 Wireless Controller 4.150.10.29
tomato_ct.c [Jun 11 2010 02:53:54]
...
無法載入Broadcom驅動程式, 自動切回64MB?
WL-500gP在v1.27.8747下, 以Oleg memtest測試
...
Allocated 58982400 bytes...trying mlock..../memtest: can't resolve symbol 'mlock'
WL-500gP於v1.27.9047beta16作memtest, 無此錯誤訊息, 64MB過關.
WL-500gP改刷Oleg 1.9.2.7-10.7(pre10a), 則可開啟128MB, memtest也過關.
所以, 硬體部分正常, 初步判斷是泰迪熊韌體出狀況, 只能靜候...
WL-500W於v1.27.9047beta16可開啟128MB, memtest也過關. 因WL-500gP memtest之錯誤訊息, 故未於v1.27.8747下測試.
謝謝ForgotFun的提示, 參考這篇, 重新編譯韌體, WL-500gP可辨識128MB RAM.
最後修改： hippo (2010-10-08 10:54:37)
離線
#6 2010-08-11 18:49:47
Re: [Tomato ND USB] WL-500gP/WL-500W 128MB RAM
最后还是用
Tomato Firmware v1.25.8735 ND USB Std
Copyright (C) 2006-2009 Jonathan Zarate
http://www.polarcloud.com/tomato/
Built on Wed, 07 Oct 2009 01:11:14 -0400
感觉还不错 稳定性 速度都能兼顾 功能也很强 现成的脱机包也能用上了。
128M也能开 折腾了3天终于完事了 呵呵
下面慢慢弄弄网站了
最後修改： lyyzh78 (2010-08-11 18:50:58)
我的简陋网站 木有了
